300C8111-DA11- G1B03 Honeywell Maxon Series 8000 Van đóng ngắt khí nén an toàn
300C8111-DA11- G1B03 of MAXON Series 8000 Valves are pneumatically actuated valves with a powerful closing spring and a large, top-mounted 360-degree open-shut visual position indicator. The Series 8000 can be ordered with a wide range of internal trim options to handle general purpose or corrosive gases and comes in a compact, space-saving design. The Series 8000 provides simple installation and low maintenance for trouble-free, long-term uninterruped operation
| Segment Name | Segment Description | Segment Choices (DEFAULT is shaded) |
Segment Choice Description | |
| Configured Item Number | VALVE SIZE | 300 | 3” (DN 80) | |
| FLOW CAPACITY | C | C - CP Body Construction | ||
| PRESSURE RATING | 81 | 81 - Pneumatic High Pressure | ||
| NORMAL POSITION | 1 | 1 - Normally-Closed Shut-Off Valve | ||
| AREA CLASSIFICATION | 1 | 1 - General Purpose | ||
| Valve Body | BODY CONNECTION | Type of body connection | D | (D) DIN PN16 flanged |
| BODY SEALS, BUMPER MATERIAL |
Material specification for valve body seals and bumper |
A | (A) Buna-N | |
| BODY MATERIAL | Type of valve body material | 1 | (1) Cast iron | |
| INTERNAL TRIM PACKAGE | Materials used for valve body internal components |
1 | (1) Trim package 1 |
|
| Actuator | PRIMARY VOLTAGE | Electrical voltage - actuator | G | (G) 24VDC |
| SWITCHES | Switch options desired, if any | 1 | (1) VOS1/VCS1 | |
| ENCLOSURE RATING | Rating of actuator enclosure | B | (B) NEMA 4X, IP65 | |
| INSTRUCTION LANGUAGE | Language for valve instructions |
0 | (0) English | |
| VISUAL INDICATION | Choice of color schemes for visual indicator | 3 | (3) Black closed / yellow open | |
