150S8111-AA11- G2B01 Honeywell Maxon Series 8000 Van đóng ngắt khí nén an toàn
150S8111-AA11- G2B01 of MAXON Series 8000 Valves are pneumatically actuated valves with a powerful closing spring and a large, top-mounted 360-degree open-shut visual position indicator. The Series 8000 can be ordered with a wide range of internal trim options to handle general purpose or corrosive gases and comes in a compact, space-saving design. The Series 8000 provides simple installation and low maintenance for trouble-free, long-term uninterruped operation
Segment Name | Segment Description | Segment Choices (DEFAULT is shaded) |
Segment Choice Description | |
Configured Item Number | VALVE SIZE | 150 | 1-1/2” (DN 40) | |
FLOW CAPACITY | S | S - Standard | ||
PRESSURE RATING | 81 | 81 - Pneumatic High Pressure | ||
NORMAL POSITION | 1 | 1 - Normally-Closed Shut-Off Valve | ||
AREA CLASSIFICATION | 1 | 1 - General Purpose | ||
Valve Body | BODY CONNECTION | Type of body connection | A | (A) ANSI (NPT) threaded |
BODY SEALS, BUMPER MATERIAL |
Material specification for valve body seals and bumper |
A | (A) Buna-N | |
BODY MATERIAL | Type of valve body material | 1 | (1) Cast iron | |
INTERNAL TRIM PACKAGE | Materials used for valve body internal components |
1 | (1) Trim package 1 |
|
Actuator | PRIMARY VOLTAGE | Electrical voltage - actuator | G | (G) 24VDC |
SWITCHES | Switch options desired, if any | 2 | (2) VOS2/VCS2 | |
ENCLOSURE RATING | Rating of actuator enclosure | B | (B) NEMA 4X, IP65 | |
INSTRUCTION LANGUAGE | Language for valve instructions |
0 | (0) English | |
VISUAL INDICATION | Choice of color schemes for visual indicator | 1 | (1) Red closed / green open |
